Description
xPart Overview
The DELIXI DTS606 1.5(6)A Mutual-Inductance Single-Phase Energy Meter is a DIN-rail mounted kWh meter for single-phase AC loads. It is designed for sub-metering in residential, light-commercial, and workshop distribution boards — including EV-charging spurs, server-room PDUs, and small industrial control panels where 5 A direct connection is insufficient. The 1.5(6)A rating means the meter is wired through an external CT (current transformer) and reads up to 6 A on its own burden. Mutual-inductance (electromagnetic) sensing gives stable readings with low starting current. Backed by our 1-year warranty and free worldwide shipping.
Typical Applications
| Use Case | Mounting | Notes |
|---|---|---|
| Residential sub-metering (apartments, rental units) | DIN-rail 35 mm | Use with CT for >6 A loads |
| EV charging spurs (single-phase wallbox) | DIN-rail 35 mm | Pair with CT rated for charger current |
| Small commercial / workshop panels | DIN-rail 35 mm | 220 / 230 V single-phase circuits |
| Server-room / PDU branch monitoring | DIN-rail 35 mm | Use with split-core CT |
| Solar / PV inverter AC-side metering | DIN-rail 35 mm | Bi-directional capable (verify model) |
Key Specifications
| Model | DELIXI DTS606 — Mutual-Inductance Type |
| Phase | Single phase (1P2W) |
| Rated Current | 1.5(6) A — via external current transformer |
| Rated Voltage | 220 / 230 V AC, 50 / 60 Hz |
| Accuracy Class | Class 1 (active energy) |
| Mounting | 35 mm DIN-rail (standard distribution board) |
| Display | Mechanical register (kWh) or LCD (variant dependent) |
| Condition | Brand New |
| Warranty | 1 Year |
Why Choose This Part?
- CT-Friendly: 1.5(6)A secondary rating lets you choose the primary CT size to match your actual load — from 30 A residential to 600 A commercial.
- Reliable Reading: Mutual-inductance measurement has decades of field history and a low starting current, so small standby loads are still counted.
- Compact DIN Footprint: Standard 1- or 2-module wide housing fits most consumer units and small distribution boards.
- Premium Quality: Built by DELIXI, an established Chinese manufacturer of electrical distribution and metering products.
- 1-Year Warranty: Covered against defects for a full year.
How to Order
Click Add to Quote above or email us at support@koeep.com with the model number (DTS606), the CT ratio you plan to use, and the destination country. We'll respond with availability and pricing within 24 hours.
Ready to order this energy meter?
Click Add to Quote or email support@koeep.com with the model number and CT ratio.
